Complete Piston, Dome, and Gasket Guide

Choosing the right combination of pistons and domes based on your crankshaft ratio and cylinder bore is essential to performance.

These components influence compression ratio, cylinder squish, and ultimately engine performance and reliability.



Understanding the Technical Essentials

To get the most out of your engine build, it is important to understand how these three factors work together to create power and ensure reliability.

1. Compression Ratio: The compression ratio is the relationship between the volume of the combustion chamber when the piston is at the bottom of its stroke versus when it is at the top.

• Higher Compression: Generally increases torque and horsepower but requires higher octane fuel to prevent detonation.
• How to Determine: It is calculated using the cylinder volume, the dome volume, and the head gasket thickness. If you change to a Long Rod Crankshaft or a different dome, your ratio will change.

2. Cylinder Squish: Squish is the distance between the top of the piston and the cylinder head at Top Dead Center (TDC). It "squishes" the air-fuel mixture into the center of the combustion chamber to create a more efficient explosion.

• The Target: Most builders look for a squish gap between 1.0mm and 1.5mm, depending on the engine's purpose.
• How to Determine: Use the "Solder Method." Insert a piece of resin-core solder through the spark plug hole toward the cylinder wall, rotate the engine by hand to crush the solder, and measure the thickness with a micrometer.

3. Crankshaft Ratio & Stroke
The ratio between your rod length and your stroke affects how long the piston "dwells" at the top of the cylinder.

• Stock Stroke: Uses a Standard 54mm Crankshaft.
• Stroker Cranks: A +4mm Stroker Crank increases displacement but requires specific domes or Spacer Plates to maintain the correct squish and prevent the piston from hitting the head.



Quick Calculation Steps Measure your current Squish: Use the solder method described above. Adjust with Gaskets: If your squish is too tight, use a thicker Base Gasket. If it’s too loose, a thinner gasket can bring the head closer to the piston. Match the Dome Angle: Ensure your piston crown angle (e.g., 13° for stock style) matches the angle of your Cylinder Domes to keep the squish band consistent.

To Use This Chart

Just begin on the left, determining crankshaft stock size by stroke and rod combo, then:

1. Match pistons and domes based on bore size and desired squish
2. Adjust base gasket thickness and add a spacer plate if needed
3. Confirm compatibility with your head, bore, and configuration before ordering

Piston, Dome, Crank Guide
